Experience unparalleled precision and efficiency with PETECH’s PDT Series High-Speed Drill Tap Center — the compact machining solution designed for modern manufacturing. Whether you’re producing precision parts in aerospace, electronics, automotive, or medical industries, this drill tap center delivers exceptional speed, accuracy, and reliability.
With its high-rpm spindle, rapid axis movements, and space-saving footprint, the PDT Series is perfect for workshops and factories looking to increase output without expanding floor space. Its advanced CNC control, rigid construction, and versatile tooling capabilities make it the go-to choice for compact milling, drilling, tapping, and light-duty machining applications.
Why Choose the PDT Drill Tap Center?
- High-Speed Drilling & Tapping: Optimized spindle speeds for rapid cycle completion without sacrificing accuracy.
- Compact & Powerful: Space-saving design ideal for workshops where floor space is at a premium.
- Versatile Machining: Handles drilling, tapping, and milling with ease in one setup.
- Exceptional Accuracy: Engineered for repeatable precision in demanding production runs.
- Cost-Effective: Competitive small CNC machine price in India while maintaining industrial-grade quality.
Key Features
- Rigid, Vibration-Free Structure: Ensures smooth operation and superior surface finishes.
- High-Performance Spindle: Ideal for both high-speed drilling and precision milling.
- Vertical CNC Milling Machine Capability: Efficiently handles multi-process operations in one machine.
- Compact Mill Design: Fits into tight manufacturing spaces without compromising performance.
- Advanced CNC Control: Simplifies programming for quick setup and minimal downtime.
Industry Applications: The PDT Series Drill Tap Center is trusted across
- Electronics & Consumer Goods: Precision holes and tapped features in lightweight components.
- Automotive Components: Fast production of brackets, housings, and engine parts.
- Medical Devices: Intricate drilling and tapping for surgical instruments and implants.
- General Manufacturing: Multi-purpose machining in small-batch or mass-production environments.
Advantages of the PDT Series Compact Mill
- Achieves high-speed cycle times for superior throughput.
- Delivers precision machining in a small CNC machine footprint.
- Functions as both a vertical milling machine and drill tap center.
- Reduces operational costs with energy-efficient design.
- Available at an attractive small CNC machine price in India backed by PETECH’s nationwide support.
Best Small CNC Milling Machine Price in India
Searching for a compact, high-performance VMC machine? The PDT Series Vertical CNC Milling Machine offers the best value in its class, blending high-speed performance, robust design, and cost efficiency.
Whether you need a drill tap center for high-volume production or a vertical machining center for multi-process operations, PETECH delivers a solution built for your success.
Request a brochure today and see how the PDT Series can transform your production line.
PDT Series – Technical Specification
DESCRIPTION | DESCRIPTION | UNIT | PDT 500 | PDT 700 |
---|---|---|---|---|
Table | Table Size | mm | 600 x 420 | 800 x 420 |
Max. Load Capacity | kg | 250 | 250 | |
T-Slots | mm | 3 X 14 – 125 | 3 X 14 – 125 | |
Dist. Table Surface to Spindle | mm | 150 – 480 | 150 – 480 | |
Spindle | Spindle Taper | type | BBT30 | BBT30 |
Spindle Speed | rpm | 20000 | 20000 | |
Spindle Driving Method | type | Direct | Direct | |
Main Spindle Power Output | kw | 3.7 / 9 | 3.7 / 9 | |
Max. Spindle Torque | nm | 30 | 30 | |
Feed | Travel (X/Y/Z) | mm | 500 / 400 / 330 | 700 / 400 / 330 |
Rapid Rate (X/Y/Z) | m/min | 48 / 48 / 48 | 48 / 48 / 48 | |
Feed Rate (X/Y/Z) | m/min | 20 | 20 | |
Guideways | type | Ball | Ball | |
ATC | Number of Tools | nos. | 21 | 21 |
Max. Tool Dia. (W/T. WO.) | mm | ø60 / ø140 | ø60 / ø140 | |
Max. Tool Length | mm | 250 | 250 | |
Max. Tool Weight | kg | 3 | 3 | |
Tool Change Time (T-T) | sec | 1.5 | 1.5 | |
Tool Change Time (C-C) | sec | 2.5 | 2.5 | |
Accuracy | Positioning | mm | 0.008 | 0.008 |
Repeatability | mm | 0.004 | 0.004 | |
Power Supply | Air Consumption | bar | 5-7 | 5-7 |
Electric Power Supply | kva | 15 | 15 | |
Voltage | v/hz | 380v±10% 50hz | 380v±10% 50hz | |
Machine | Machine Dimensions | mm | 1750 x 2230 x 2230 | 1850 x 2230 x 2230 |
Machine Weight | kg | 3000 | 3000 |
