Performance Horizontal Lathe - PHL Series
Get in touch
Maximize your workshop productivity and precision with the PHL Performance Horizontal CNC Lathe — engineered for industries that demand speed, accuracy, and reliability. The PHL Series is rigorously tested for high-speed operations while maintaining exceptional rigidity, delivering high productivity rates without compromising tight tolerances. This makes it the perfect choice for demanding machining environments.
Whether you’re looking for a CNC lathe machine, horizontal lathes, or a reliable CNC turning center, the PHL Series offers superior precision and dependable performance, ensuring high-quality output every time.
Why Choose the PHL Performance Horizontal Lathe?
- High-Speed Precision: Optimized for fast operations while maintaining tight tolerances across complex parts.
- Exceptional Rigidity: Robust design minimizes vibrations, ensuring consistent accuracy in high-demand applications.
- Versatile CNC Turning Machine: Suitable for a wide range of industries, including automotive, aerospace, and heavy engineering.
- Cost-Effective: Offers competitive lathe machine price without sacrificing performance or durability.
- User-Friendly Interface: Simplified controls reduce setup time and boost operator efficiency.
- Reliable After-Sales Support: Backed by PETECH’s nationwide service network and comprehensive warranty, ensuring minimal downtime and peace of mind.
Key Features of the PHL Horizontal CNC Lathe
- High Rigidity Construction: Stable and robust structure that minimizes deflection for superior machining quality.
- Precision CNC Control: Advanced CNC system providing smooth, accurate, and reliable turning operations.
- High-Speed Spindle Options: Flexible spindle speeds to handle everything from roughing to finishing.
- Versatile Machining: Supports various workpiece sizes and materials for a wide range of applications.
- Easy Maintenance: Designed for quick and easy access, reducing downtime and maximizing uptime.
Industry Applications & Benefits: The PHL Performance Horizontal Lathe excels across multiple sectors
- Automotive: Achieve consistent, high-volume production of precision shafts, bushings, and other components.
- Aerospace: Machine critical parts requiring tight tolerances and superior surface finishes, such as turbine shafts and landing gear components.
- Heavy Engineering: Handle large, complex, and heavy workpieces efficiently thanks to a robust design and powerful spindle options.
- General Manufacturing: Adaptable to a variety of materials including steel, aluminum, and high-strength alloys, making it perfect for diverse machining needs.
Advantages of the PHL CNC Turning Machine
- Delivers exceptional accuracy and repeatability even in challenging machining conditions.
- Enables faster production cycles with optimized tooling and spindle speeds.
- Helps reduce overall operational costs through energy-efficient, durable construction.
- Features an operator-friendly interface for quick training and seamless workflow integration.
Get the Best CNC Turning Machine Price in India
If you are in the market for a CNC lathe machine, horizontal lathe, or vertical turning lathe, the PHL Performance Series from PETECH is a proven choice. Offering competitive CNC turning machine prices without compromising quality or precision, PETECH is your partner for reliable CNC solutions.
PHL Series – Technical Specification
SECTION | DESCRIPTION | UNIT | PHL1600 | PHL2000 | PHL2100 | PHL2500 | PHL2500L | PHL2500XL |
---|---|---|---|---|---|---|---|---|
Capacity | Max.Swing Over Bed | mm | 400 | 490 | 500 | 600 | 600 | 600 |
Max.Turning Length | mm | 300 | 420 | 540 | 850 | 1200 | 1950 | |
Max.Turning Dia. | mm | 260 | 300 | 400 | 450 | 450 | 450 | |
Chuck Size | inch | 6 | 8 | 8 | 10 | 10 | 10 | |
Spindle | Spindle Nose | type | A2-5 | A2-6 | A2-6 | A2-8 | A2-8 | A2-8 |
Bar Capacity | mm | 42 | 52 | 52 | 75 | 75 | 75 | |
Spindle Bore | mm | 52 | 65 | 65 | 86 | 86 | 86 | |
Spindle Speed Range | r/min | 4500 | 3500 | 3500 | 2500 | 2500 | 2500 | |
Spindle Power | kw | 7.5 / 11 | 11 / 15 | 11 / 15 | 15 / 18.5 | 15 / 18.5 | 15 / 18.5 | |
Max Spindle Torque | nm | 103.6 | 140 | 191 | 350 | 350 | 350 | |
X&Z Axes | Travel (X / Z Axis) | mm | 145 / 320 | 175 / 460 | 230 / 575 | 240 / 900 | 240 / 1250 | 240 / 2000 |
Rapid Traverse Rate (X / Z) | m/min | 30 / 30 | 30 / 30 | 30 / 30 | 20 / 20 | 20 / 20 | 20 / 20 | |
Tailstock | Tailstock Travel | mm | 160 | 350 | 370 | 800 | 1145 | 1900 |
Spindle Taper | MT | 4 | 4 | 4 | 5 | 5 | 5 | |
Turret | Tool Turret | nos. | 8 | 12 | 12 | 12 | 12 | 12 |
Od Tool Shank Size | mm | 20 X 20 | 20 X 20 | 25 X 25 | 25 X 25 | 25 X 25 | 25 X 25 | |
Boring Blade Dia. | mm | 32 | 32 | 40 | 40 | 40 | 40 | |
Radon Tool Selection | Yes / No | Bi-Directional | Bi-Directional | Bi-Directional | Bi-Directional | Bi-Directional | Bi-Directional | |
Coolant | Coolant Pressure | bar | 3 | 3 | 3 | 3 | 3 | 3 |
Coolant Tank Capacity | Its | 140 | 120 | 140 | 160 | 160 | 160 | |
Machine | Machine Dimensions | mm | 2200 x 1430 x 1650 | 2500 x 1750 x 1600 | 3620 x 2800 x 1750 | 3320 x 2276 x 1861 | 3895 x 2326 x 1861 | 4200 x 2100 x 1800 |
Machine Weight | kg | 2400 | 3650 | 3800 | 5800 | 6350 | 6800 | |
Controller | 10.4 Inch Screen | model | Fanuc OiTF Plus | Fanuc OiTF Plus | Fanuc OiTF Plus | Fanuc OiTF Plus | Fanuc OiTF Plus | Fanuc OiTF Plus |
