Versatile T-Slotted Rotary Tables
Get in touch
The PRC Series T-slotted rotary tables are ideal for securing medium to large parts or fixtures. These sturdy tables, with six precision T-slots, offer versatility as they can be mounted vertically or horizontally. The large through-holes accommodate bar feeding and special fixture-locating needs, providing a robust solution.
Specifications
Brochure
Specifications
PRC210
PLATTER | UNIT | METRIC |
---|---|---|
Bore Diameter | mm | 50.8 |
Platter Diameter | mm | 210 |
Max Weight on Platter (Vertical) | Kg | 90 |
Max Weight on Platter (Horizontal) | Kg | 180 |
Number of Std T-Slots | Numbers | 6 |
Spindle | Unit | Metric |
Max Speed | ° /sec | 180 |
Max Torque | Nm | 257 |
Runout Max | mm | 0.013 |
Center Height | mm | 152.4 |
Backlash | arc-sec | 30 |
Brake Torque @ 100 psi/6.9 bar | Nm | 340 |
Gear Ratio | 50 1 | |
Brake | Hydro Pneumatic | |
Indexing | Unit | Metric |
Accuracy (±) | arc-sec | ± 20 |
Repeatability | arc-sec | ± 4 |
Max Rotation/Step (with rotary control) | 999.999 ° | |
General | Unit | Metric |
Power Requirement | 115 VAC ± 10% @15 A | |
Operating Temp (max ambient) | °C | 38 |
Air Requirements | Unit | Metric |
Air Pressure Max bar | bar | 10.3 |
Dimensions – Shipping | Unit | Metric |
Export Crate | cm | 69 x 54 x 54 |
Weight | Kg | 85 |
